TM 9-2320-364-20-3
2-1938
WARNING
3. ALL TIRES ON AXLES NO. 3 THROUGH NO. 5 WILL NOT DEFLATE.
INITIAL SETUP
1.
Are all CTIS connectors
fully connected?
Secure loose
connections. Verify
repair, go to Step 8 of
this Fault.
START
YES
NO
Tires on Axles No. 3 through
No. 5 inflate.
Tires on Axles No. 1 and No. 2
deflate.
CTIS lines and components not
leaking.
CTIS wire harness connection
faulty.
CTIS controller faulty.
Wiring harness faulty.
Rear manifold faulty.
Deflate valve solenoid faulty.
Deflate valve faulty.
KNOWN INFO
POSSIBLE PROBLEMS
TEST OPTIONS
REASON FOR QUESTION
Visual inspection.
CTIS will not operate properly
if connectors are loose or
unplugged.
2-26. CENTRAL TIRE INFLATION SYSTEM (CTIS) TROUBLESHOOTING (CONT).
Tools and Special Tools
Tool Kit, General Mechanic’s: Automotive
(Item 74 Appendix G)
STE/ICE-R (optional) (Item 3, Appendix G)
Multimeter (Item 44, Appendix G)
Jumperwire
Personnel Required
Two
Equipment Condition
Engine OFF, (TM 9-2320-364-10)
Parking brake applied, (TM 9-2320-364-10)
Wheels chocked, (TM 9-2320-364-10)
CTIS rear manifold cover removed, (Para 13-9)
Load Handling System (LHS) extended fully,
(TM 9-2320-364-10)
CTIS turned on, (TM 9-2320-364-10)
Front access cover opened,
(TM 9-2320-364-10)
References
TM 9-2320-364-10
TM 9-4910-571-12&P
Read WARNING
on Page 2-1939
|
